ProLine TS93 E
Drying cabinets
The ProLine drying cabinet series offer versatile, energy-efficient drying solutions for various industries. Designed to handle everything from workwear and uniforms to PPE, they provide gentle, effective drying without mechanical wear. Ideal for professional and industrial use, ensures fast, reliable results while preserving fabric quality.
Description
The ProLine TS93 E drying cabinet offers cutting-edge efficiency and reliability for large-capacity industrial laundry needs. With unmatched capacity of up to 35 lbs / 16 kg and a unique 100 ft / 32 m hanging length, it provides exceptional flexibility for drying various garments and textiles. Its robust construction ensures longevity, making it ideal for commercial dry cleaners, hotels, shared laundry spaces, and industrial facilities.
Specifications
Main data
- Product type
- Drying cabinet
- Product name
- ProLine TS93 E
- Product no.
- 131034
- Warranty
- Three-year limited
- Type
- Air vented
- Hanging length, ft/m
- 105/32
- Capacity (dry weight), lb/kg
- 35/16
- Interior capacity, cu ft/l
- 73,1/2070
- Energy consumption, kWh
- 6.4
- Drying capacity, oz/min / g/min
- 2.9/81
- Noise emission, dB(A)
- 65
- Prepared for payment system
- Standard
- Reversable swinging hanging rail system
- Standard
- Connection cable
- Standard
- Drying time (normal temperature), min
- 64
- Residual moisture before drying, %
- 43
- Residual moisture after drying, %
- 0
Electrical Installation
- Supply voltage, V
- 3~N/400V/50Hz
- Electric heating, W
- 9000
- Electric fan, W
- 500
- Total effect, W
- 9500
- Protection, A
- 16
Specifications
- Outer: WxDxH, in
- 71x31.5x77
- Outer: WxDxH, mm
- 1800x800x1955
- Shipping dimensions: WxDxH, in
- 75x31x42
- Shipping dimensions: WxDxH, mm
- 1915x790x1060
- Weight, lb
- 518
- Weight, kg
- 235
- Shipping weight, lb
- 606
- Shipping weight, kg
- 275
- Minimum ceiling height, in/mm
- 67/2215
- Doors open, °
- 190
Ventilation
- Outlet exhaust, Øin/mm
- 2.36/160
- Outlet airflow, cfm/m³/h
- 177/300
- Max pressure drop, psf/Pa
- 4.4/210
- Max airflow (at 0% pressure), cfm/m³/h
- 324/550
Documents
Manuals
- picture_as_pdfUser manual TS93 E
Product sheet
- picture_as_pdfProduct sheet ProLine drying cabinet TS93 E
Key features
Capacity & design
35 lbs dry weight
73.1 cu ft interior
105 ft hanging length
Rotating hanging rail (90°) with doors opening 190°
Advanced drying system
Automatic & manual programs
Preset start time
Temperature & humidity tracking
Electric heated air drying
Efficiency & safety
Energy-efficient
Gentle drying without mechanical action
Double overheat protection
Cool down mode at program end
Durability & versatility
Powder-coated galvanized steel
Sturdy construction
Interior lighting
Adjustable feet
Versatile drying options for delicate and hard-to-dry textiles
Unrivaled capacity
With the ability to accommodate up to 35 lbs / 16 kg of laundry in a single cycle, the ProLine TS93 E sets the standard for high-capacity drying cabinets. Its spacious interior and unique 100 ft / 32 m hanging length offer unparalleled flexibility, allowing for the efficient drying of a wide range of garments and textiles. The ProLine TS93 E is the ultimate solution for all your industrial drying needs.

Energy-efficient laundry operations
Despite its impressive capacity, the ProLine TS93 E is remarkably energy-efficient, consuming just 6.4 kWh per dry cycle. This not only reduces energy costs but also minimizes its environmental impact, making it a sustainable choice for any laundry operation.

Robust construction
Built to withstand the rigors of regular use, the ProLine TS93 E features a sturdy construction that ensures reliability and longevity. Its durable design makes it ideal for commercial dry cleaners, hotels, shared laundry spaces and industrial facilities where reliability is paramount.

Features a Humidity Tracking System (HTS) with sensors that monitor both temperature and humidity. It detects moisture levels and automatically stops the drying process once the laundry reaches optimal dryness, ensuring time and energy efficiency.
Humidity and temperature tracking
